Low-Pressure PM Inverter Air Compressors
Product Overview
Comps Low-Pressure PM Inverter Air Compressors are specifically designed for low-pressure, high-flow industrial applications. Equipped with permanent magnet variable frequency technology, the compressors maintain excellent efficiency even under low-pressure operating conditions. The optimized airend profile significantly improves volumetric efficiency, making these systems an ideal choice for industries requiring continuous low-pressure compressed air.
Designed for demanding production environments, Low-Pressure PM Inverter Air Compressors help reduce energy consumption while maintaining stable airflow and pressure.
Key Features
● Optimized screw rotor profile for improved low-pressure volumetric efficiency
● High-efficiency permanent magnet motor for lower energy consumption
● Stable pressure control under low-pressure operating conditions
● Large air delivery capacity for high-flow applications
● Variable frequency control automatically adjusts output based on air demand
● Reliable operation with reduced operating costs
Strong R&D Capabilities
Comps maintains an independent research and development department dedicated to compressor innovation and product optimization. Our engineering team continuously develops specialized solutions for different operating conditions, including low-pressure applications. Advanced design software and comprehensive testing platforms ensure every product delivers dependable performance and long-term reliability.
Applications
Suitable for:
Textile manufacturing
Chemical fiber production
Cement conveying
Wastewater aeration
Powder conveying
Glass manufacturing
Technical Specifications
|
Air Delivery (m³/min) |
Working Pressure (bar) |
Motor Power (kW) |
|
13.5 |
5 |
55 |
|
20 |
5 |
75 |
|
23.5 |
5 |
90 |
|
28.5 |
5 |
110 |
|
32.5 |
5 |
132 |
|
41.0 |
5 |
160 |
|
43 |
5 |
185 |
|
48.0 |
5 |
200 |
|
52.5 |
5 |
220 |
|
60 |
5 |
250 |
