Two Stage Screw Air Compressor
Product Overview
The two stage screw air compressor adopts advanced two-stage compression technology with intercooling design, providing improved compression efficiency compared with traditional single-stage systems.
The compressor uses two sets of screw rotors to complete the compression process in stages. By optimizing the pressure ratio distribution between the two stages, the compression temperature is reduced and the service life of major components is improved.
Two Stage Compression Advantages
The two-stage compression structure with intercooling technology can significantly improve energy efficiency compared with conventional compression methods.
Key performance advantages include:
● Optimized low-pressure and high-pressure rotor matching
● Lower compression temperature
● Balanced rotor load distribution
● Extended bearing service life
● Improved performance in high-pressure applications
The design is especially suitable for applications requiring high pressure and large airflow capacity.
Transparent Production Service
Comps provides customers with regular production updates during manufacturing, including photos and videos at important production stages.
From raw material preparation and component processing to assembly, testing, packaging, and shipment, each key step can be tracked and recorded. This transparent production process allows customers to monitor order progress and better manage project schedules.
The two stage screw air compressor is manufactured under strict quality control to provide reliable performance for demanding industrial applications.
Applications
Suitable for:
High-pressure compressed air systems
Large airflow applications
Continuous production facilities
Energy-saving upgrade projects
Industrial plants requiring improved efficiency
Technical Specifications
|
Air Delivery (m³/min) |
Working Pressure (bar) |
Power (kW) |
|
10 |
8 |
45 |
|
7.5 |
10 |
45 |
|
6.5 |
13 |
45 |
|
12 |
8 |
55 |
|
10.5 |
10 |
55 |
|
9 |
13 |
55 |
|
14.5 |
8 |
75 |
|
13 |
10 |
75 |
|
11.5 |
13 |
75 |
|
20 |
8 |
90 |
|
16.5 |
10 |
90 |
|
15 |
13 |
90 |
|
22.5 |
8 |
110 |
|
19.6 |
10 |
110 |
|
17.5 |
13 |
110 |
|
26.5 |
8 |
132 |
|
23 |
10 |
132 |
|
20.5 |
13 |
132 |
|
32.5 |
8 |
160 |
|
30 |
10 |
160 |
|
26 |
13 |
160 |
